Embedded 2D Barcode Scanner USB for Payment Kiosk/Automatic device/Access Control System

Product Information

Model Number
TEK-E2-2
Brand Name
TEKLEAD
Origin
China
Small Orders
Accepted

Key Specifications/ Special Features

Product Parameters



TypeFixed Wired Barcode Scanner Module
MaterialABS +PC
ColorBlack
Power SupplyDC 5V ±5%
Weight50±5g（Without the cable）
InterfaceUSB, RS-232
SensorPlanar CMOS sensor
Light SourceRed CCD(aiming) ,white LED (lighting)
Professor32-bit MCU
Decoding Capability1D:Codabar,Code11,Code39/Code93,UPC/EAN,Code128/EAN128,InterLeaved2of5,Matrix2of5,MSI CODE,Standard2of5.

2D:QR CODE ,PDF417 ,Data Matrix
ResolutionCode39 5mil, QR 8.7mil, PCS45%
Scanning Depth5MIL CODE39: 5--12 CM
15MIL CODE39 : 4--25 CM
10MIL CODE93 : 4--21 CM
15MIL UPC/EAN: 4--25 CM
20MIL QR ： 4--25 CM
Trigger ModeManual, Automatic induction, Continuous scanning
Scanning Width5 * 5 cm² -- 30 * 30 cm²
Prompt ModeBuzzer, Indicator Light(LED)
Print ContrastMin 35%
Scanning AngleRoll35°,Pitch65°,Yaw65°
Operating Temp.0 to 50 ºC / 32 to 122 ºF
Storage Temp.0 to 50 ºC / 32 to 122 ºF
Operating Humidity5 - 95% (No Condensation)
IP Grade≥IP54
ESD Protection15kv
Shock Resistance 1.5m free fall on concrete surface



We can ODM modules for customers, like Wiegand interface, small size, etc. Just tell us your requirements.

aileen.shao (at) gzteklead (dot) com


Details Images







Product Parameters



TypeFixed Wired Barcode Scanner Module
MaterialABS +PC
ColorBlack
Power SupplyDC 5V ±5%
Weight50±5g（Without the cable）
InterfaceUSB, RS-232
SensorPlanar CMOS sensor
Light SourceRed CCD(aiming) ,white LED (lighting)
Professor32-bit MCU
Decoding Capability1D:Codabar,Code11,Code39/Code93,UPC/EAN,Code128/EAN128,InterLeaved2of5,Matrix2of5,MSI CODE,Standard2of5.

2D:QR CODE ,PDF417 ,Data Matrix
ResolutionCode39 5mil, QR 8.7mil, PCS45%
Scanning Depth5MIL CODE39: 5--12 CM
15MIL CODE39 : 4--25 CM
10MIL CODE93 : 4--21 CM
15MIL UPC/EAN: 4--25 CM
20MIL QR ： 4--25 CM
Trigger ModeManual, Automatic induction, Continuous scanning
Scanning Width5 * 5 cm² -- 30 * 30 cm²
Prompt ModeBuzzer, Indicator Light(LED)
Print ContrastMin 35%
Scanning AngleRoll35°,Pitch65°,Yaw65°
Operating Temp.0 to 50 ºC / 32 to 122 ºF
Storage Temp.0 to 50 ºC / 32 to 122 ºF
Operating Humidity5 - 95% (No Condensation)
IP Grade≥IP54
ESD Protection15kv
Shock Resistance 1.5m free fall on concrete surface



We can ODM modules for customers, like Wiegand interface, small size, etc. Just tell us your requirements.

aileen.shao (at) gzteklead (dot) com


Details Images
