Fiber optic Distribution box

The price of the website is for reference only. If you need to purchase, please contact the salesperson for a quote. The actual quote shall prevail.

Model Number:LW-GFS23-PA08/16

Product Name: Fiber optic Distribution box 08/16core

Product Description:

Fiber optic Distribution box 08/16core is designed to provide protection for fiber optic connectors and splices in indoor or outdoor environments (IP65 Rated). The enclosure has a built in,

Swing-out mini splice tray plus a bulkhead panel with SC cutouts ports. 2 or 3 Cable access ports with built in weather-tight grommets allow for easy cable installation.

1. User familiar industry interface, using high impact plastic,

2. It can accommodate 1*8 and 1*16 PLC Splitter, 1*12 distrbution pigtail, 16*0.9/2.0 simplex pigtail

3. Anti-UV, Ultra violet resistant and rainfall resistant

4. Up to 16 FTTH drops.

5. Wall and Pole Mountable

6. SC/ST/LC/FC connection available

Model Number:LW-GFS23-PA16

Product Name: Fiber optic Distribution box 16core

Product Description:

Fiber optic Distribution box 16core is designed to provide protection for fiber optic connectors and splices in indoor or outdoor environments (IP65 Rated). The enclosure has a built in,

Swing-out mini splice tray plus a bulkhead panel with SC cutouts ports. 2 or 3 Cable access ports with built in weather-tight grommets allow for easy cable installation.

1. User familiar industry interface, using high impact plastic,

2. It can accommodate 1*8 and 1*16 PLC Splitter, 1*12 distrbution pigtail, 16*0.9/2.0 simplex pigtail

3. Anti-UV, Ultra violet resistant and rainfall resistant

4. Up to 16 FTTH drops.

5. Wall and Pole Mountable

6. SC/ST/LC/FC connection available

Model Number:LW-GFS23-PA32A

Product Name: Fiber optic Distribution box 32core

Product Description

Description:

1. It is good for storage of fixing cable achieves.

2. It is applicable for (indoor and outdoor) (pole-mounted, wall-mounted).

3. The splicing part is convenient for protection and maintenance engineering.

4. Adapter baseboard and optical installation box baseboard uses a rotary design.

Details:

1. Type Model: GFS23-TXPA32A

2. Appearance size(mm): 370*420*125

3. Weight: 4.26KG

Model Number: LW-GFS23-PA32B

Product Name: Fiber optic Distribution box 32core

Product Description

Description:

1. It is good for storage of fixing cable achieves.

2. It is applicable for (indoor and outdoor) (pole-mounted, wall-mounted).

3. The splicing part is convenient for protection and maintenance engineering.

4. Adapter baseboard and optical installation box baseboard uses a rotary design.

Details:

1. Type Model: GFS23-TXPA32B

2. Appearance size(mm): 350*410*130

3. Weight: 2.74KG
