Product Information
Key Specifications/ Special Features
Choose BelFone, Choose Success
30 years of expertise in mission and business critical communications
Consult BelFone Expert for Customized Products and Solutions
Digital/analog Dual Modes
BF-TD872 gives you a smooth transition from the analog world to the digital.
A Longer Battery Life
BF-TD872 can function for longer than any conventional analog radios. (digital 17hours; analog 13 hours)
Excellent Audio Quality
Excellent digital audio quality comes from the AMBE+2TM vocoder and FEC technology
Radio Priority-Based Interruption
This function enables a radio with higher level to interrupt communications between radios with lower levels, giving higher priority to radios with higher levels. This means better dispatching efficiency.
Scan/Monitor(Programmable)
At a convenient push of a button you can monitor all the conversations on your channel or you can scan conversations on different channels.
Private Call, Group Call And All Call (Programmable)
The versatile calling functions bring more efficiency to your teamwork.
DMO Pseudo Trunk
The user can choose slot 1 or slot 2 for communications. When one slot is occupied the radio will automatically switch to the free slot. Frequency efficiency is greatly 100% increased.
Specifications
| General | |
| Frequency Range | VHF: 136-174MHZ; UHF: 350-390MHz/ 400-480MHz/ 450-520MHz |
| Channels | 128 |
| Zones | 8 |
| Channel Spacing | 12.5KHz/ 25KHz |
| Working Voltage | DC7.4V (±20％) |
| Frequency Stability | ±1.5ppm |
| Antenna Impedance | 50Ω |
| Battery Capacity | Real 2600mAh |
| Battery Average Working Time | Digital 17 hours; Analog 13 hours |
| Dimension | 60(L)* 37(W)* 130(H) mm |
| Weight | 259g (including battery pack) |
| Transmitter | |
| Power Output | High power: 5W; Middle power: 3W; Low power: 1W |
| 4FSK Modulation | 12.5KHz data only: 7K60FXD; 12.5KHz data and voice: 7K60FXE |
| FM Modulation | 12.5KHz: 8K50FXD; 25KHz: 16KΦF3E |
| Modulation Limitation | +/- 2.5KHz |
| FM Noise | -40dB |
| Spurious Emission | -36 dBm≤1GHz/-30 dBm≥1GHz |
| Adjacent Channel Power | ≤-60dB |
| Frequency Response | +1/-3dB |
| Vocoder | AMBE+2™ |
| Audio Distortion | ＜3% |
| Receiver | |
| Digital Sensitivity | 5% BER: 0.25 uV |
| Analog Sensitivity | 0.25 uV (12 dB SINAD) |
| Intermodulation | 65dB |
| Adjacent Channel Selectivity | 60dB |
| Spurious Suppression | 70dB |
| FM Noise | -40dB |
| Frequency Response | +1/-3 dB |
| Audio Power | 500mW |
| Audio Distortion | 3% (typical) |
| Conduction Radiation | -57 dBm |
| Environmental Specifications | |
| Operating Temperature | -20℃~+60℃ |
| Storage Temperature | -30℃~+85℃ |
| Water Proof | IP54 |
| Shock & Vibration | MIL-STD-810C/D/E/F |
