Product Information
Key Specifications/ Special Features
Product Name
Custom Medical Cable Assemblies for Patient Monitoring and Diagnostic Equipment
Search Keywords
medical cable assembly, healthcare cable, diagnostic cable, patient monitoring cable
Model Number
EDG-MED-030
| Parameter | Specification |
|---|---|
| Application | Patient monitoring, diagnostic devices, imaging systems, surgical equipment |
| Cable Type | Multi-core medical-grade cable with shielding |
| Conductor Material | High-purity stranded copper / silver-plated copper |
| Insulation Material | TPU / Silicone / TPE, biocompatible |
| Operating Voltage | 12V – 250V AC/DC |
| Current Rating | Up to 10A |
| Wire Gauge | AWG 28 – AWG 18 (0.08mm² – 0.75mm²) |
| Jacket Material | Medical-grade TPU / Silicone (flexible and sterilizable) |
| Protection Level | IP65 / IP67 waterproof options |
| Operating Temperature | -20°C to +80°C |
| Standards Compliance | ISO 13485, IEC 60601, RoHS, REACH |
| Testing | 100% continuity, insulation resistance, pull-off test, sterilization test |
Medical cable assemblies are critical components in healthcare equipment, providing safe and reliable connections for patient monitoring, diagnostic, and surgical systems. Our custom medical cable assemblies are designed with biocompatible materials such as TPU and silicone, ensuring patient safety while maintaining flexibility and durability.
Each medical cable assembly is built with high-purity stranded copper or silver-plated copper conductors to deliver accurate signal transmission and stable electrical performance. The cables can be customized with multi-core configurations, shielding, and reinforced jackets to minimize electromagnetic interference, ensuring precise data collection in sensitive medical environments.
These assemblies are widely used in ECG/EKG systems, ultrasound machines, blood pressure monitors, infusion pumps, surgical tools, and imaging systems. The medical-grade jackets are resistant to frequent sterilization procedures, including autoclaving and chemical disinfection, making them suitable for repeated clinical use. Waterproof and IP67-rated versions are available for devices exposed to liquids or outdoor medical applications.
Our medical cable assemblies comply with ISO 13485 and IEC 60601 standards, guaranteeing safety, reliability, and long service life. Each assembly undergoes 100% electrical and mechanical testing, including continuity, insulation resistance, pull-off strength, and sterilization endurance. With more than 20 years of experience in cable design and manufacturing, we provide OEM and ODM solutions tailored to healthcare manufacturers worldwide.
Whether you need a diagnostic cable, patient monitoring cable, or custom surgical device cable, our medical cable assemblies deliver precise performance, safety, and durability in critical healthcare applications.
