Phone jack ,keyboard,switch PJ2011C

Shop product specifications, Price only for reference, not the actual transaction price, the specific price to contact customer

service quotation, Welcome to consult! !! Can be customized according to drawings,

samples of various non-standard parts. Good quality, reasonable price, welcome your patronage!

Size: Ø2.5mm

SMT type

Installation height: 2.5mm

Schematic: 4 poles with switch and more

Housing material: LCP

Housing color: black, pink, blue, gray and more

Terminal: silver plating or gold plating

Packing: tape and reel packing

Basic information

Item:pink Audio interface phone jack receptacle connector

Brand: BSUN

Mounting system: SMT

Plastic material: LCP

Shell material: SUS

Terminal material: C5210

Application: mobile phone, iPad, GPS navigator, LCD TV

Pin: 5 pins

Technology information:

1. Materials:

Housing: LCP

Contact: copper alloy C5210

Shell: SUS

2. Plating:

Contact: plated 50u'' Ni overall

Plated Au selective contact area

Plated 100u'' Sn over Ni on solder area

Shell: plated 50u'' Ni overall

Plated 1u'' Au selective contact area

Packing:

1. Tape reel packing

2. Diameter of reel: 13"

3. Cover tape: transparent

4. Use K=K carton to prevent transport damage

Shipping:

By sea, by air delivery or express such as DHL, TNT, UPS

Refund and replacement:

1. We provide 30 days warranty

2. If the items you purchase from our store are not of perfected quality, that is they don't work electronically to manufacturers specifications, simply return them to us for replacement or refund

3. If the items are defective, please notify us within 3 days of delivery

4. Any items must be returned in their original condition to qualify for a refund or replacement

5. Buyer is responsible for all the shipping cost incurred

Service:

1. All of our sales are RD engineer before, can provide professional service for you

2. Your inquiry related to our product and price will be replied within 12 hours

Well-trained and experienced staff is to answer all your inquiries in English of course

3. OEM and ODM projects are highly welcome

We have strong R and D team here to help

4. Your business relationship with us will be confidential to any third party

Good after-sale service offered, get back if you got question

Phone jack

Contact current rating 1A

Contact resistance 50M ohms max

Insulation resistance 100M ohm min

Dielectric withstanding 300V AC min

Durability 5000 cycles min

Connector mating forces 0.30-3.00kgf

Connector unmaking forces 0.30-3.00kgf
