Phone jack ,keyboard,switch PJ3096F

Shop product specifications, Price only for reference,

not the actual transaction price, the specific price to contact customer

service quotation, Welcome to consult! !!

Can be customized according to drawings,

samples of various non-standard parts. Good quality,

reasonable price, welcome your patronage!

3.5mm 1/8 inch audio jack

5 contacts 3 conductors

For TRS stereo plug

Right angle

Through holes PCB

2 inner switch

Temperature: -30 to +70 degree Celsius

Rated load: DC30V 0.5A

Contact resistance: 30 Ohm max.

Insulation resistance: 100M ohm min

Withstand voltage: AC500V (50Hz) min

Insert force: 3-20N

Life: 50000 times
