Product Information
Key Specifications/ Special Features
Solar charge controller electrical circuit control pcb board maker
Specification
Layer: 4 layers
Material: FR-4
Copper Thickness (in OZ): 1OZ
Finish Board Thickness: 1.6 mm
Solder Mask: Green
Silkscreen: White
Surface Finish: HASL
Minimum line width and line spacing: 4/5 mil
| Value | Specification |
|---|---|
| Material | FR-4,FR1, CEM-1, CEM-3,Aluminum, Ceramic, Metal-backed Laminate, etc.Also make Crockery, Taconic, Rogers PCBs etc. |
| Remarks | High Tg CCL is Available(Tg>=170℃) |
| Finish Board Thickness | 0.2 mm-6.00mm(8mil-126mil) |
| Surface Finish | Gold finger(>=0.13um), Immersion Gold(0.025-0075um), Plating Gold(0.025-3.0um), HASL(5-20um), OSP(0.2-0.5um) |
| Shape | Routing、Punch、V-cut、Chamfer |
| Surface Treatment | Solder Mask(black, green, white, red, blue, thickness>=12um, Block, BGA) |
| Silkscreen(black, yellow, white) | |
| Peel able-mask(red, blue, thickness>=300um) | |
| Minimum Core | 0.075mm(3mil) |
| Copper Thickness | 1/2 oz min; 12oz max |
| Min Trace Width & Line Spacing | 0.075mm/0.1mm(3mil/4mil) |
| Min Hole Diameter for CNC Drilling | 0.1mm(4mil) |
| Min Hole Diameter for Punching | 0.6mm(35mil) |
| Biggest panel size | 610mm * 508mm |
| Hole Position | +/-0.075mm(3mil) CNC Drilling |
| Conductor Width(W) | +/-0.05mm(2mil) or +/-20% of original |
| Hole Diameter(H) | PTHL:+/-0.075mm(3mil) |
| Non PTHL:+/-0.05mm(2mil) | |
| Outline Tolerance | +/-0.1mm(5mil) CNC Routing |
| Warp & Twist | 0.70% |
| Insulation Resistance | 10Kohm-20Mohm |
| Conductivity | <50ohm |
| Test Voltage | 10-300V |
| Panel Size | 110 x 100mm(min) |
| 660 x 600mm(max) | |
| Layer-layer misregistration | 4 layers:0.15mm(6mil)max |
| 6 layers:0.25mm(10mil)max | |
| Min spacing between hole edge to circuitry pattern of an inner layer | 0.25mm(10mil) |
| Min spacing between board outline to circuitry pattern of an inner layer | 0.25mm(10mil) |
| Board thickness tolerance | 4 layers:+/-0.13mm(5mil) |
Q1.For PCB quotation what files format does Xingda need?
A:Gerber, Protel 99SE, DXP, PADS 9.5, AUTOCAD, CAM350 are OK.
Q2.MOQ and what is Xingda's fastest delivery time?
A:1pcs. Sample to mass production all can be supported by Xingda.
Q3.How to test PCB boards?
A:AOI, Fly probe testing, Text fixture testing, FOC etc. for bare PCB.
Q4.Can you do PCB or circuit design?
A:Yes,we have design team including software, hardware and structure engineers.
We can supply customized design service. Give your idea and we can make it true.
Q5.Which payment terms does Xingda accept?
A:T/T, Western Union, PayPal, Money Gram and so on.
Solar charge controller electrical circuit control pcb board maker
Specification
Layer: 4 layers
Material: FR-4
Copper Thickness (in OZ): 1OZ
Finish Board Thickness: 1.6 mm
Solder Mask: Green
Silkscreen: White
Surface Finish: HASL
Minimum line width and line spacing: 4/5 mil
| Value | Specification |
|---|---|
| Material | FR-4,FR1, CEM-1, CEM-3,Aluminum, Ceramic, Metal-backed Laminate, etc.Also make Crockery, Taconic, Rogers PCBs etc. |
| Remarks | High Tg CCL is Available(Tg>=170℃) |
| Finish Board Thickness | 0.2 mm-6.00mm(8mil-126mil) |
| Surface Finish | Gold finger(>=0.13um), Immersion Gold(0.025-0075um), Plating Gold(0.025-3.0um), HASL(5-20um), OSP(0.2-0.5um) |
| Shape | Routing、Punch、V-cut、Chamfer |
| Surface Treatment | Solder Mask(black, green, white, red, blue, thickness>=12um, Block, BGA) |
| Silkscreen(black, yellow, white) | |
| Peel able-mask(red, blue, thickness>=300um) | |
| Minimum Core | 0.075mm(3mil) |
| Copper Thickness | 1/2 oz min; 12oz max |
| Min Trace Width & Line Spacing | 0.075mm/0.1mm(3mil/4mil) |
| Min Hole Diameter for CNC Drilling | 0.1mm(4mil) |
| Min Hole Diameter for Punching | 0.6mm(35mil) |
| Biggest panel size | 610mm * 508mm |
| Hole Position | +/-0.075mm(3mil) CNC Drilling |
| Conductor Width(W) | +/-0.05mm(2mil) or +/-20% of original |
| Hole Diameter(H) | PTHL:+/-0.075mm(3mil) |
| Non PTHL:+/-0.05mm(2mil) | |
| Outline Tolerance | +/-0.1mm(5mil) CNC Routing |
| Warp & Twist | 0.70% |
| Insulation Resistance | 10Kohm-20Mohm |
| Conductivity | <50ohm |
| Test Voltage | 10-300V |
| Panel Size | 110 x 100mm(min) |
| 660 x 600mm(max) | |
| Layer-layer misregistration | 4 layers:0.15mm(6mil)max |
| 6 layers:0.25mm(10mil)max | |
| Min spacing between hole edge to circuitry pattern of an inner layer | 0.25mm(10mil) |
| Min spacing between board outline to circuitry pattern of an inner layer | 0.25mm(10mil) |
| Board thickness tolerance | 4 layers:+/-0.13mm(5mil) |
Q1.For PCB quotation what files format does Xingda need?
A:Gerber, Protel 99SE, DXP, PADS 9.5, AUTOCAD, CAM350 are OK.
Q2.MOQ and what is Xingda's fastest delivery time?
A:1pcs. Sample to mass production all can be supported by Xingda.
Q3.How to test PCB boards?
A:AOI, Fly probe testing, Text fixture testing, FOC etc. for bare PCB.
Q4.Can you do PCB or circuit design?
A:Yes,we have design team including software, hardware and structure engineers.
We can supply customized design service. Give your idea and we can make it true.
Q5.Which payment terms does Xingda accept?
A:T/T, Western Union, PayPal, Money Gram and so on.
