DVB-S2 Receiver 2024

DVBS/S2 Receiver

Chipset: NT78346SE or NT78306SE

Mechanical: Metal Case

Interface: AV, HDMI, RS-232, 2*USB2.0, IR, LNB IN/OUT

Encrypt: ASIC Type

Tunner: AIROHA AV2018 On board with shield

Demodulator: Embed in CPU

SMPS: Separate SMPS

LNB IN: IEC 169-24, F-Type, Female

AV: Mini-Jack convert to CVBS+L/R Audio

RSS: Mini-Jack convert to RS-232

USB: 4 PIN Female USB 2.0

HDMI: 19 PIN Female HDMI 1.3

MPEG: MPEG-2 SD, MPEG-2 HD, H.264/MPEG-4 SD, H.264/MPEG-4 HD

SCPC/MCPC: SCPC and MCPC receivable from C/Ku band satellite

PAL/NTSC: Automatic PAL/NTSC conversion

Favorite: 8 different favorite groups selection

OSD: Multi-language for options

EPG: Fully support to 7 days Electronic Program Guide(EPG)

Color OSD: 256 color/16bit On Screen Display

NIT Search: Automatic network search for newly added transponders

DiSEqC: DiSEqC1.0/1.1/1.2/USALS Motor fully support, 13/18V, 0/22K, 0/12V LNB control

Parent Control: Parental control for channels

Software Upgrade: Software upgrades through USB port, Support OTA and HTTP/FTP upgrade.

Timer: 9 Timer Reservations, automatically switch to a specific channel

Subtitle: Subtitle support DVB EN300743 and EBU

Teletext: Teletext support DVB ETS300472 by VBI and OSD

Multi-Resolution Output: Dual display – HD and SD simultaneous

Game: Games for options (Tetris, Othello, Sudoku.)

USB Wifi Dongle: Ralink5370/7601

3G Dongle: E303s/E177/E173/E153/E3131/E1750/E1752C

CPU Frequency: 550MHz

Flash: 32Mbit/4Mbyte SPI FLASH

DDR: 512Mbit
